The Cicada: a push-pull vacuum tube amplifier build

Well, 2017 is more than half over now. This means I should probably post something to get at least one post in for this year. I’ve been meaning to do a write up about this project for a while, but time isn’t as freely available as I would like it to be. Go figure. I had been wanting to try a push-pull tube amp build for years and scrapped together a design from parts I had lying around. I play a Gretsch G5265 baritone guitar with bass VI strings (this was its original configuration when I got it back in ’08), and I’ve had a hard time finding an amp that really suits the tone of the mini-humbuckers and it’s very deep tone. I decided to etch together a blackface Bassman-like amp with a tone stack capable of giving it the upper-mid range that it needs to bring out the high notes of the instrument. Unfortunately, I still haven’t gone through a rigorous analysis of the design other than some tone stack simulations in LTspice, but I’ll give out the schematic and details of the build.

6L6GC amp schematic

First off, the secondary voltage of the transformer should read around 330 VAC. I’m not sure what I was smoking when I put 600 VAC, but mistakes… yeah. Other than that, it’s the schematic that made noise happen. Unlike a typical Bassman, it lacks a choke and the negative feedback resistor value is pretty large by comparison. I just swapped out values until I liked the sound and the oscillations stopped happening. I might swap this out with a 22k resistor again, but I can’t complain so far about the tone. There is one side of a 12AU7 (V2b) which is currently unused. I might make a simple phase shift oscillator of that later to make a tremolo circuit. If someone wanted to swap out 12AX7s in this design, the thing would be hella dirty and loud for a 40-ish watt amplifier (I still have to measure the actual wattage delivered to the load).

6L6GC amp tone simulation
6L6GC amp tone simulation

Here is a plot of the magnitude of the tone stack simulation with the treble at noon, the bass at 9 o’clock, and the mid all the way up. The behavior of the stack is interesting as changing any one of the pots can have a sometimes dramatic effect on the position of the mid center frequency. This is one of the made drawbacks of passive tone stacks since the change in resistance of any potentiometer changes the transfer function for the network. However, the tone stack does lend itself to also listening to recorded music when setup properly. We’ve actually used this as a PA head in conjunction with a subwoofer which worked out really well. It’s bright nature actually seems to work well for vocals and low-mid while the sub picks up anything under 150 Hz or so.

6L6GC amp guts

I have a number of pictures that show how the layout progressed from right to left inside the chassis. Basically, I just started on the right side closest to the power transformer and worked towards the input. The biasing circuitry is towards the front of the amp by the large filter caps in the picture.

6L6GC tube glow

I was reading through Theory and Application of Electron Tubes [1] and discovered that the blue plasma color is actually caused by a spray of electrons from the cathode that actually overshoot the anode and slam into the glass. In the picture, you can see how the blue light only cover the area surrounding the big gray metal anode inside the glass. My new JJs that I put in there don’t have such an extreme blue color to them during operation.

Lastly, pictured above is the final build with the steel cage situated on top. The chassis is aluminum while the cage is steel. Both are manufactured by the fine folks at Hammond. I picked these up off CE Distribution’s website for a decent price. There’s definitely some room for improvement in the overall, but I really didn’t think it would work at all. I do think that it’s one of the nicest sounding amps I’ve ever owned regardless of the fact that I built it. I’ll post some sound samples eventually with some different instruments so anyone who stumbles upon this post can hear what the amp sounds like at lower volumes at least.

[1] Reich, H. (1944). Theory and Application of Electron Tubes. New York [usw.]: Mc Graw-Hill.

Milling PCBs with Linux…

This is a quick outline of my LinuxCNC setup. Basically, I have an old HP Compaq Pentium IV that’s running Xubuntu 14.04. I had to install the Xenomai real-time kernel in order to make it work with LinuxCNC 2.5.2 which controls my Chinese CNC3020T.

I’ve been using 0.1mm 30° engraving bits for etching which have worked nicely. For drilling, I’ve got some carbide 0.7mm drills. I haven’t broken any of them thus far. I’ve setup a Dremel 3000 with a 220-01 rotary tool work station for additional drilling by hand.


For sanding, I’ve been starting off a freshly etched board with a 180 grit sanding block and then moving down to a 320 grit for smoothing. So far, I’ve been impressed with the results. The following picture shows a single pass isolation trace after sanding at ~75x magnification.




I believe it’s time to put an end to this kind of insanity. There can be no economic growth if human beings continue to be reckless with the environment that supports them. Clean air, water, and soil are necessary for all life to flourish. That ought to be a priority.

Differential Amplifier w/ Cathode Follower

Differential Amplifier with Cathode Follower

This is a circuit designed for a classroom project whereby the instructions were to “improve” a differential amplifier circuit. The differential amplifier design is essentially an exercise in understanding the inner workings of an opamp, and it effectively works in the same way. The figure below is a schematic for the differential amplifier without the cathode follower output stage. In the LTspice simulation, the input signal is connected to the V+ terminal and the V- terminal is connected to ground. There is no feedback loop between the output and either input terminal making this a high-gain open-loop configuration. However, adding a resistor from V- to ground and one from the output terminal to V- would accomplish the same results as a non-inverting opamp.


I wouldn’t say that adding a cathode follower “improves” the output stage of the amp. It was more an experiment in comparing different solid-state output stages with a vacuum tube stage operating at very low voltages. However, I will say that this thing sounded amazing with the couple of guitars I tested through it. Putting a potentiometer in the feedback network allowed me to play with different gain settings. It’s a very bright sound overall giving lots of high-end sparkle, but the breakup was quite remarkable. I suspect this might be a very usable configuration for a tube mic preamp or a number of audio applications. Hopefully, I will get an opportunity to revisit this before too long.

For those of you interested in the ins and outs of this experiment, you can download our full report here.

Already Dead Tapes releases Document II

“As we march along on our mission to create a diverse and expansive creative community, we reach a new milestone: 200 releases. To this end, we bring you ‘Document II’, a retrospective cassette that comes with a Golden Ticket good for downloads of our last 100 releases. This is a one-time limited edition of 200 golden cassettes with hand numbered gold fold j-cards and golden tickets.

The mix itself is a collection of just a few of our favorite tracks from the last one hundred releases, a diverse collection of tracks that span genres, from artists all over the world. As always, thank you for listening.”
– Joshua Tabbia, Already Dead Tapes, 2016

3-stage amplifier analysis


analysis of a 3-stage amp. working up to delivering some power to a load. the CC section is not worked out here, but the final design delivered a whopping 18 mW to an 8 ohm load. i found better results with a class AB configuration than this class A design as expected. this is a good exercise at running through the small-signal analysis.


Pixie: 40m QRP CW transceiver


first post of 2015. it’s a small pocket size 40m CW transceiver that i got off of eBay for a mere $8. i’ve mainly used this while i’m at school to flex my cognitive abilities and decode the communications of extra class morse pros. the transceiver has a tuning range of 7.023-7.026MHz (maybe) which puts it in that tiny 250kHz portion of the 40m band reserved for amateur extras. at 5:30pm PST, it’s virtually an endless cacophony of signals. however, i was able make out a signal 565 miles south this afternoon from KI6JD using only the support railing as an dipole antenna. i don’t think he heard my response, but i would expect that considering my total radiating output is somewhere around 0.25 watts. also, my morse skills are lackluster at the moment, so i might have just sent gibberish out on the air. who knows.

DOD FX55B SupraDistortion – BigBuff Mod


Here’s another in a line now of DOD pedal mods. For this FX55B, I decided to go for more of a BigMuff sound. Playing around with this pedal initially, I found it to be like most mass-produced distortion/fuzz effects. It had a very thin sound and that notorious volume drop that you may have heard on a high-school band’s first album. The lows were almost non-existent when the effect was engaged. I found the following schematic and, with a few simple changes, came out with a distortion pedal with considerable gain, massive lows, and a smoother, more rounded square wave.


Overall, the idea here was to get more from the pedal by employing some germanium to smooth out the harshness and to increase the overall output. The output is now considerably higher as long as the tone knob is set closer to 10 o’clock. At noon, the mixing is practically useless. At the 4 o’clock position, you get more of a thin, trash punk type of sound with an excessive noise floor. The sound sample demonstrates the effect with the tone set at about 10:30-11 and first contrasts the distortion setting. The third set shows off the tone below 10 o’clock. The last set shows what the tone does when you sweep through it.

Class AB amplifier test


this was an attempt at designing a simple transformer-less class AB amplifier using two BJT power transistors. i setup the USB fan to protect against thermal runaway and cool off the transistors during operation. it took me looking over several schematics to realize that the the emitters of both the PNP and NPN transistors were tied together. the collector of the PNP (TIP32C) is grounded which is obvious! the synapses just weren’t seeing the PNP symbol as upside down. it’s definitely something i’ll have to work on. i’d like at some point to have a nice 40W amp based on a similar configuration.
